螺杆上料机
特点
ASL系列螺旋上料机专为塑料及粉体生产加工行业设计制造
本机与物料接触部分全部采用不锈钢制作，可与各种规格挤出机、高速混合机、塑料搅拌机配套使用，广泛适用于各类粉状、粒状、回料破碎等物料的上（送）料用途
本系列机型单机上料高度可达2-6料，并可多机串联使用，抽送上料速度为1-3吨/每小时。具有：自动控制加料，维修方便，安全可靠，提高工作效率等优点
Screw feeder
Features
The ASL series of screw feeders are designed and manufactured for the plastics and powders processing industry , The contact part of the machine and the material are all made of stainless steel , it can be used with extruders of various specifications , high-speed mixers and plastic mixers ; it is widely used in all kinds of powder , granular and recycled materials . (send ) material use
The height of the single machine of this series can reach 2-6 meters , it can be used in series with multiple machines , and the feeding speed is 1-3 tons / hour . it has the advantages of automatic control feeding , convenient maintenance , safety and reliability , and improved work efficiency
真空吸料（粉）机
特点
微电脑操作控制程序，过载，缺料报警
300G采用高速整流马达，噪音小，寿命长
主机与料斗一体式设计，体积小，重量轻
700G采用高速整流马达，体积小，吸料强，适合用于新料输送
400G、800G、900G及大功率吸料机采用感应式高压风机，噪音小，寿命长
800G具有逆转自动清除粉尘功能
主机与料斗分体设计，安全，简便，独立滤清装置，方便清除粉尘
Vacuum Suction (powder ) Machine
Features
Microprocessor programmed operation , overload , material shortage alarm
300G adopted high-speed motor , *** all noise , long service life
The host and the hopper integrated design , *** all volume , light weight
700G adopted high-speed motor , *** all volume , suction is strong , suitable for new material conveying
800G , 900G using induction type high pressure fan , low noise ,long life
螺旋振动垂直提升机
螺旋振动提升机采用当今最先进的结构设计及模具成型工艺，针对冷却降温干燥和无损输送场合而开发的特定设备，广泛应用于塑料、化工、食品、矿业等加工行业多种物料形态的冷却，干燥和提升输送，在塑料及化工行业我们具有近50套各类型振动提升机工程应用，具备大、中、小全系列提升机量产化制造经验，并打破了大型振动提升机被进口设备垄断的历史
Spiral Vibration Vertical Hoist
Spiral vibrating conveyor adopts state-to-art structural design and molding process , it is specific equipment , developed for cooling , drying and nondestructive conveying way , it is widely used in processing industries such as plastic , chemistry , food and mining industry , etc for cooling ,drying and lifting and conveying of materials in multiple forms In plastic and chemical industries , we have obtained approximately 50 sets of various kinds of spiral vibrating conveyor engineering applications , had experience in mass manufacturing of *** all , intermediate and Barge full series of vibrating conveyor and broken the history for large-scale vibrating conveyor to be monopolized by imported equipment
特点
一机多用，同时满足垂直输送和降温干燥
结构紧凑，占地面积小
可按客户生产需求定制，最高提升高度8米，最大输送量4T/H
品牌振动电机，满足长时间连续化生产，工作稳定，维护简便
振动盘为2-4MM厚304不锈钢，采用大型模具一次成型工艺，外圈与内圈各自经拉伸形成螺旋挡板及加强筋板，再与不锈钢中心管连续无应力焊接，最大程度上克服了振动产生的扭曲应力和金属疲劳开裂，整体结构强度完全达到德制设备标准
振动盘螺旋均匀，无发拱翘曲现象，物料以排队形式沿螺旋匀速平稳向上输送，在任何高度均无明显回流现象（与第一代提升机显著区别）
输送槽内部圆滑无死角积料，便于不同产品的切换清理，交叉污染风险大大降低
通过振动结构最优化设计，最大程度实现惯性振动，噪音低于80分贝，相对第一代提升机，电耗降低30-50%
中心立柱支撑结构，更稳固安全
停车制动设计，可在2秒内完全停止振动，避免停车共振破坏
进料和出料采用加厚及加固设计，提高使用寿命
可按客户要求设计变频控制，按实际要求调节输送时间和速度
可按客户要求设计风冷，提高冷却效率
可按客户要求增加振动盘夹套结构，通冷却介质以强化冷却
Features
A machine serves several purposes , and meanwhile it satisfies vertical conveying cooling and drying
Structure is compact , with *** all space required
It can be customized according to production requirements of customer , maximum lifting height is 8m and maximum conveying capacity is 4t/h
Brand vibrating motor can meet long-time continuous production with stabile operation and easy maintenance , Vibration disc , is made of 2-4 mm thick 304 stainless steel , adopting one – time forming process of large –scale mould
The outer ring and the inner ring is formed to be . spiral baffle plate and reinforcement plats separately by tension . Discs are continuously welded with stainless steel central tube without stress , which can overcome the torsional stress and metal fatigue crack generated by vibration so that the overall structure strength fully meets the standard of equipment manufactured in germany
Vibration disc screws are uniform without warping , Materials is transported upward in line along the spiral at uniform and *** ooth speed and has no back-flow at any height . (it is the significant difference from the first generation type )
Inside the conveying groove is *** ooth without dead angle for accumulated materials Convenient for switching to clean different products and greatly reduces cross contamination risks
Through optimization design of vibration structure it maximizes to realize inertial vibration with noise reduced to 80 dB and power consumption is reduced by 30-50% , compared with the first generation type
With central pillar support structure , it is more stable and safe
With shut-down brake design , it can stop vibration within 2 seconds , avoiding resonance damage when shut-down
It adopts thickening and reinforcement design for inlet and outlet so as to improve service life
It can be designed for frequency convertor control according to customer requirements , and adjust conveying time and speed
It can be designed for additional air cooling according to customer requirements , and improve cooling efficiency
Additional cooling channel disk design is optional
工作原理
利用对称振动电机产生斜向高频振动力偶，使物料以振动形式沿转盘螺旋形向上爬升，高温物料在长距离输送过程中得以充分传热和散热
Working Principle
It utilizes symmetric vibrating motor to produce oblique high frequency vibration couple so as to make material spiral upward along turntable in vibration mode , high temperature material can get sufficient heat tran *** ission and heat dissipation during long distance transport process
特点
代替传统风送或气相输送系统，更易于清理，无易损部件
能耗明显降低，节电节气
物料冷却均匀彻底，无内热积聚效应，避免因长时间高温导至变色和降解，产品品质明显改善
充分利用自身散热干燥颗粒表面水分，不经过额外干燥即可满足客户常规注塑要求，提高产品附加值
Features
Replace traditional pneumatic conveying pipeline or dense phase conveying system , it can be more easy to clean without easily wearing parts
It can reduce energy consumption obviously and save electricity and gas
Material is cooled uniformly and thoroughly , avoiding discoloration and degradation caused by tong-time high temperature , and product quality is improved obviously
Make fuji use of self –heat dissipation to dry moisture on granule surface . Without additional drying ,it can satisfy , the conventional injection molding requirements and increase the added value of the products
